Set RM1 - The Law of Reflection

Problem
Points
0/1
0/1
0/1
0/3
0/4
0/1
Total Score
0/11
Percentage
0 %
Assignment Overview

Use the law of reflection to identify a variety of angle measures formed as light reflects off a flat surface such as a plane mirror.

 1. RM1Q1
Points: 0/1

A light ray approaches a mirror at an angle of incidence of 28°. What is the angle of reflection?

  1. Angle of Reflection

    °

Help Links
 2. RM1Q2
Points: 0/1

A light ray approaches a mirror at an angle of 19° with the mirror surface. What is the angle of reflection of this light ray?

  1. Angle of Reflection

    °

Help Links
 3. RM1Q3
Points: 0/1

If an incident ray of light makes an angle of 51° with a plane mirror surface then the angle of reflection is ___°.

  1. Angle of Reflection

    °

Help Links
 4. RM1Q4
Points: 0/3

A ray of light approaches a plane mirror with an angle of incidence of 35°. Determine the …

  1. … angle of reflection.

    Angle of Reflection

    °

  2. … the angle the incident ray (I) makes with the mirror (M).

    Angle Between I and M

    °

  3. … the angle the incident ray (I) makes with the reflected ray (R) - the smallest of the two options.

    Angle Between I and R

    °

Help Links
 5. RM1Q5
Points: 0/4

In a physics lab, Ray Zuvlite arranges two mirrors with a right angle orientation as shown. Ray then directs a laser line at one of the mirrors. The light reflects off both mirrors as shown. If angle A is 35°, then what is the angle measure for angle …

  1. … B?

    Angle B

    °

  2. … C?

    Angle C

    °

  3. … D?

    Angle D

    °

  4. … E?

    Angle E

    °

Help Links
 6. RM1Q6
Points: 0/1

Two plane mirrors are positioned at right angles to one another. A ray of light strikes one mirror at an angle of 16° to the normal. It then reflects towards the second mirror that makes a right angle with the first mirror. What is the angle of reflection of the light ray off the second mirror?

  1. 2nd Angle of Reflection

    °

Help Text

Use a diagram to assist with your answer.

Help Links
