Particles .. Words .. Formulas - Questions

The Particles .. Words .. Formulas Concept Builder is comprised of 36 questions. The questions are divided into 18 different Question Groups and spread across three difficulty levels. Questions in the same group are rather similar to one another. The Concept Builder is coded to select at random a question from each group until a student is successful with that group of questions.

There are three different difficulty levels that can be engaged in through the Concept Builder. Those three difficulty levels are differentiated as follows:

  • Apprentice Difficulty Level: Question Groups 1-6 ... Particle representations include only three elements; formulas are simple.
  • Master Difficulty Level: Question Groups 7-12 ... Particle representations include only three elements; questions are slightly more complex.
  • Wizard Difficulty Level: Question Groups 13-18 ... Particle representations include three elements; questions are complex.

The questions from each group are shown below. Teachers are encouraged to view the questions in order to judge which activities are most appropriate for their classes. We recommend providing students two or more options.

The Physics Classroom grants teachers and other users the right to print these questions for private use. Users are also granted the right to copy the text and modify it for their own use. However, this document should not be uploaded to other servers for distribution to and/or display by others. The Physics Classroom website should remain the only website or server from which the document is distributed or displayed. We also provide a PDF that teachers can use under the same conditions. We have included a link to the PDF near the bottom of this page.



Particles .. Words .. Formulas



Apprentice Difficulty Level
Question Group 1
Question 1
Consider the Particle Representation and accompanying Atom Key. Identify the one statement that does not match the diagram.



There are four atoms of the compound nitrogen.
There are three molecules of the compound water (H2O).
There are two molecules of the compound ammonia (NH3).
There are two molecules of the compound nitrogen monoxide (NO).


Question 2
Consider the Particle Representation and accompanying Atom Key. Identify the one statement that does not match the diagram.



There are four atoms of the compound nitrogen monoxide (NO).
There are three molecules of the compound water (H2O).
There are two molecules of the compound ammonia (NH3).
There are two molecules of the element nitrogen.


Question Group 2
Question 3
Consider the Particle Representation and accompanying Atom Key. Identify the one statement that does not match the diagram.



There are three compounds of the element hydrogen.
There are two different compounds in the diagram.
There is a total of 10 molecules in the diagram.
There is one molecule of the element oxygen.


Question 4
Consider the Particle Representation and accompanying Atom Key. Identify the one statement that does not match the diagram.



There is only one compound of the element oxygen.
There are two different compounds in the diagram.
There is a total of 10 molecules in the diagram.
There are three molecules of the element hydrogen.


Question Group 3
Question 5
Consider the Particle Representation and accompanying Atom Key. Identify the one statement that does not match the diagram.



There are three atoms of the element hydrogen.
There are two molecules of the compound water (H2O).
There are two molecules of the compound ammonia (NH3).
There are two molecules of the element oxygen.


Question 6
Consider the Particle Representation and accompanying Atom Key. Identify the one statement that does not match the diagram.



There are two compounds of the molecule water (H2O).
There are two molecules of the compound ammonia (NH3).
There are three molecules of the element hydrogen.
There are two molecules of the element oxygen.


Question Group 4
Question 7
Consider the Particle Representation and accompanying Atom Key. Identify the one formula that does not describe the parts of the diagram.

2 N4
3 H2O
2 NH3
2 NO


Question 8
Consider the Particle Representation and accompanying Atom Key. Identify the one formula that does not describe the parts of the diagram.


N2O2
3 H2O
2 NH3
2 N2


Question Group 5
Question 9
Consider the Particle Representation and accompanying Atom Key. Identify the one formula that does not describe the parts of the diagram.

2 O
3 H2
3 NO
3 H2O


Question 10
Consider the Particle Representation and accompanying Atom Key. Identify the one formula that does not describe the parts of the diagram.

6 H
O2
3 NO
3 H2O


Question Group 6
Question 11
Consider the Particle Representation and accompanying Atom Key. Identify the one formula that does not describe the parts of the diagram.

3 O2
3 H2
2 NH3
2 H2O


Question 12
Consider the Particle Representation and accompanying Atom Key. Identify the one formula that does not describe the parts of the diagram.

2 H3
2 O3
2 NH3
2 H2O





Master Difficulty Level
Question Group 7

Question 13
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

4 molecules of the element oxygen and 3 molecules of the compound ammonia (NH3)
3 molecules of the element oxygen and 3 molecules of the compound ammonia (NH3)
4 molecules of the compound oxygen and 3 molecules of the compound ammonia (NH3)
12 molecules of the element oxygen and 3 molecules of the compound ammonia (NH3)


Question 14
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?



3 molecules of the element oxygen and 4 molecules of the compound ammonia (NH3)
3 atoms of the element oxygen and 4 molecules of the compound ammonia (NH3)
3 atoms of the compound oxygen and 4 molecules of the compound ammonia (NH3)
12 molecules of the element oxygen and 4 molecules of the compound ammonia (NH3)



Question Group 8
Question 15
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

4 atoms of the element copper and 3 molecules of the compound water (H2O)
4 elements of the atom copper and 3 compounds of the molecule water (H2O)
4 atoms of the element copper and 3 atoms of compound oxygen and 6 atoms of compound hydrogen
4 elements of copper atoms and 3 molecules of the compound water (H2O)


Question 16
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

3 atoms of the element copper and 4 molecules of the compound water (H2O)
3 elements of the atom copper and 4 compounds of the molecule water (H2O)
3 atoms of the element copper and 4 atoms of compound oxygen and 8 atoms of compound hydrogen
3 elements of copper atoms and 4 molecules of the compound water (H2O)



Question Group 9
Question 17
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

4 atoms of the element sodium and 3 molecules of the compound nitrogen dioxide (NO2)
4 elements of the atom sodium and 3 compounds of the molecule nitrogen dioxide (NO2)
4 atoms of the element sodium and 3 atoms of compound nitrogen and 6 atoms of compound oxygen
4 elements of sodium atoms and 3 molecules of the compound nitrogen dioxide (NO2)

Question 18
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

3 atoms of the element sodium and 4 molecules of the compound nitrogen dioxide (NO2)
3 elements of the atom sodium and 4 compounds of the molecule nitrogen dioxide (NO2)
3 atoms of the element sodium and 4 atoms of compound nitrogen and 8 atoms of compound oxygen
3 elements of sodium atoms and 4 molecules of the compound nitrogen dioxide (NO2)

Question Group 10
Question 19
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

4 O3  +  3 NH3
3 O4  +  3 NH3
3 O4  +  3 N  +  3 H3
12 O3  +  3 N  +  9 H3


Question 20
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

3 O3  +  4 NH3
9 O3  +  4 NH3
3 O3  +  4 N  +  4 H3
9 O3  +  4 N  +  12 H3



Question Group 11
Question 21
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

4 Cu +  3 H2O
Cu4 +  3 H2O
4 Cu +  3 H2  +  3 O
Cu4  +  3 H2  +  3 O


Question 22
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

3 Cu +  4 H2O
Cu3 +  4 H2O
3 Cu +  4 H2  +  4 O
Cu3  +  4 H2  +  4 O


Question Group 12
Question 23
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

4 Na  +  3 NO2
Na4  +  3 NO2
4 Na  +  3 O2  +  3 N
Na4  +  3 O2  +  3 N


Question 24
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

3 Na  +  4 NO2
Na3  +  4 NO2
3 Na  +  4 O2  +  4 N
Na3  + 4 O2  +  4 N




Wizard Difficulty Level
Question Group 13

Question 25
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

There are eight atoms of diatomic hydrogen molecules.
There are four atoms of the element sodium.
There are three molecules of the compound hydrogen chloride (HCl).
There are two molecules of the compound water (H2O).


Question 26
Consider the Particle Representation and accompanying Atom Key. Which one statement does NOT correctly describe the diagram?

There are three molecules of the compound sodium.
There are three molecules of diatomic chlorine.
There are two molecules of the compound hydrogen chloride (HCl).
There are three molecules of the compound water (H2O).


Question Group 14
Question 27
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

There are four elements of the compound copper.
There are three diatomic molecules of the element nitrogen.
There are two molecules of the compound water (H2O).
There are two molecules of the compound nitrogen dioxide (NO2).

Question 28
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

There are eight atoms of the molecule nitrogen.
There are three atoms of the element copper.
There are three molecules of the compound water (H2O).
There is one molecule of the compound nitrogen dioxide (NO2).

Question Group 15
Question 29
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

There are three elements of the compound copper.
There are four diatomic molecules of the element hydrogen.
There are two molecules of the compound hydrogen peroxide (H2O2).
There is one molecule of the compound nitrogen monoxide (NO).

Question 30
Consider the Particle Representation and accompanying Atom Key. Which verbal description correctly describes the diagram?

There are six atoms of the element oxygen.
There are three atoms of the element copper.
There are three molecules of the compound nitrogen monoxide (NO).
There is one molecule of the compound hydrogen peroxide (H2O2).

Question Group 16
Question 31
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

4 Na   +   3 HCl   +  4 O2   +   2 H2O
4 Na   +   3 HCl   +  8 O  +   2 H2O
Na4   +   3 HCl   +  4 O2   +   2 H2O
Na4   +   3 HCl   +  8 O  +   2 H2O


Question 32
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

3 Na   +   2 HCl   +  3 Cl2   +   3 H2O
3 Na   +   2 HCl   +  6 Cl  +   3 H2O
Na3   +   2 HCl   +  3 Cl2   +   3 H2O
Na3   +   2 HCl   +  6 Cl   +   3 H2O


Question Group 17
Question 33
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

4 Cu   +   2 NO2   +   2 H2O +   3 N2
4 Cu   +   2 NO2   +   2 H2O +   6 N
4 Cu4   +   2 NO2   +   2 H2O +   2 N3
4 Cu4   +   N2O4   +   H4O2      +   3 N2

Question 34
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

3 Cu   +   NO2   +   3 H2O +   4 N2
3 Cu   +   NO2   +   3 H2O +   2 N4
Cu3   +   NO2   +   3 H2O +   8 N
3 Cu3   +   NO2   +   H6O3   +   4 N2

Question Group 18
Question 35
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?


3 Cu   +   NO   +   2 H2O2   +   4 H2   +   2 O3
3 Cu   +   NO   +   2 H2O2   +   2 H4   +   3 O2
3 Cu3   +   NO   +   2 H2O2   +   4 H2   +   2 O3
3 Cu   +   NO   +   H4O4   +   4 H2   +   2 O3


Question 36
Consider the Particle Representation and accompanying Atom Key. Which set of formulas correctly describes the diagram?

3 Cu   +   3 NO   +   H2O2   +   3 H2   +   2 O3
3 Cu   +   3 NO   +   H2O2   +   2 H3   +   3 O2
3 Cu3   +   N3O3   +   H2O2   +   3 H2   +   2 O3
Cu3   +   N3O3   +   H2O2   +   3 H2   +   2 O3
